DIN 920

Equivalent Standards

DIN 920 Slotted Pan Head Screws, Small Head Dimensions

d	d1 max	k	n	t min	b
M 1.6	2.3	1	0.3	0.5	4
M 2	2.8	1.2	0.3	0.6	6
M 2.5	3.5	1.5	0.4	0.75	7
M 3	4	1.8	0.5	0.9	9
M 4	5.5	2.4	0.6	1.2	12
M 5	6.5	2.7	0.8	1.3	15
M 6	8	3.1	1	1.5	18
M 8	10	3.8	1.2	1.9	24
