DIN 7500 C

Equivalent Standards

DIN 7500 C Thread forming screws with cross recessed raised cheese head Z Dimensions

thread d	m	dk max	k max
M2	0	4	1.6
M2.5	1	5	2
M3	1	6	2.4
M4	2	8	3.1
M5	2	10	3.8
M6	3	12	4.6
M8	4	16	6
