DIN 74361 C
» Resources » Dimensional Standards » Nuts » DIN 74361 C
» Resources » Dimensional Standards » Nuts » DIN 74361 C
| Screw | d min | d2 max | h | r |
|---|---|---|---|---|
| M12x1.5 | 12.5 | 23 | 6 | 12 |
| M14x1.5 | 14.5 | 26 | 6 | 14 |
| M18x1.5 | 18.5 | 29 | 7 | 16 |
| M20x1.5 | 20.5 | 34 | 8 | 18 |
| M22x1.5 | 22.53 | 34 | 8 | 18 |
